01
High area
Filtration areas range up to 20 m².
Industrial air filtration
Dust-Collection Filter Cartridge Manufacturer
We manufacture pleated spun-bonded polyester filter cartridges with application-specific surface treatments for industrial dust collection and pulse cleaning.
Sri Bharathi Tech manufactures and supplies Pleated Dust-Collection Filter Cartridges from Ankleshwar, Gujarat, India, with grade, size and configuration selection based on the buyer’s process and equipment.
Operating principle
How the filtration product works
A dust-collection cartridge draws contaminated air through pleated media. Particles are retained mainly at the outer surface while clean air passes to the cartridge core. Pulse-jet or other cleaning reverses flow briefly to release the dust cake into the collector hopper.
Pleating fits a large filtration area into a compact envelope. Open pleat spacing and surface treatment influence cake release, pressure drop and cleaning-air demand.
Media design
Construction and process behaviour
Sri Bharathi 100% polyester spun-bonded media is formed into a cylindrical pleated pack, supported by a metal core and encapsulated with metal end caps. Sponge-rubber sealing can provide positive fitment. The media is thermally bonded without a binding agent.
Available treatments include PTFE coating or lamination, aluminium or stainless-steel antistatic coatings and fire-retardant coating. The coating must be matched to the dust hazard and operating environment.
What to evaluate
Important features and benefits
02
Surface filtration
Pleated polyester supports dust-cake release and pulse cleaning.
03
Multiple treatments
Moisture/oil, antistatic, fire-retardant and sticky-dust options are available.
04
Open pleat spacing
Supports cleaning access and reduces dust bridging.
05
Retrofit potential
Pleated bags may replace some conventional bags without collector modification.
06
Multiple mount styles
Flange, three-lug and standard configurations are listed.
Technical data
Specification and enquiry checklist
The specifications below provide a practical basis for product selection. Final grade and configuration are matched to the intended process conditions.
| Selection parameter | Product details | Engineering relevance |
|---|---|---|
| Base medium | 100% polyester spun-bonded media. | Confirm temperature and chemical exposure. |
| Length | 300–1400 mm to customer requirement. | Match tube sheet, cleaning system and available clearance. |
| Diameter | 150, 225 and 325 mm. | Controls fit and filtration area. |
| Filtration area | 0.96–20.0 m². | Verify actual pleat geometry for the quoted element. |
| Treatments | PTFE coating/lamination, aluminium or stainless antistatic, fire retardant. | Choose around dust release, moisture, static and combustibility risk. |
| Mounting | Flange, three-lug and standard. | Provide drawing and sealing details. |
| Cleaning | Application-specific pulse or reverse-air system. | Air pressure and frequency affect life and emissions. |
Process fit
Applications and selection considerations
Industries served include pharmaceuticals, steel, power, powder coating, cement, chemicals, metals and minerals, and paints and pigments. Dust testing and hazard assessment are essential before selection.
Combustible-dust caution
Antistatic or fire-retardant media alone does not make a dust collector explosion safe. The site must assess dust explosibility, ignition sources, grounding, venting or suppression, isolation and applicable regulations with qualified specialists.
Questions engineers ask
Frequently asked questions
What does PTFE treatment change?
A coating or membrane can improve surface release, moisture/oil resistance or fine-particle control depending on construction. Confirm the quoted treatment.
Does more media area always improve performance?
Not if pleats are packed so tightly that dust bridges or cleaning air cannot reach the valleys. Area, pleat spacing and cleaning must be balanced.
Can a cartridge solve a combustible-dust hazard?
No. It is one component of a collector system. A formal dust-hazard and explosion-protection design is required.
What dimensions are needed for a replacement?
Provide overall length, OD, ID, end-cap design, mount type, gasket dimensions, current media and collector model.
Continue specifying
Related filtration products
Application support
Send us your operating conditions
Share your fluid, temperature, desired clarity, existing equipment and dimensions. Our team can then recommend a suitable construction and prepare a quotation.
